041 REAR SHOCK ABSORBER YAMAHA FZ1 – 2006 2013
041 REAR SHOCK ABSORBER YAMAHA FZ1 – 2006 2013
041 REAR SHOCK ABSORBER YAMAHA FZ1 – 2006 2013
Product example for shock absorber
Please note that this picture may differ from the actual product application
S46HR1C1S (WITH ABS AND WITHOUT ABS)
Single tubePiston diameter: 46 mm
Monotube high pressure gas type of shock absorber with hose mounted external reservoir
Adjustable rebound damping on single tube shocks.
Adjuster wheel above the end eye
Adjustable compression damping.
Adjuster wheel or slot on the reservoirHose mounted hydraulic spring preload adjuster
Length: 320 mm Stroke: 67,5 mm Rate N/mm: 120 N/mm Mounted spring: 01095-44
