Torque Converter Driven Description:
Replaces COMET 40/44 Series Torq-A-Verter models
For 8-18hp engines within the 1600-3300 RPM range
40 series torque converter driven clutch is a symmetrical inline small engine clutch
The 40 series is heavily used in three wheelers, ATV’s, LTV’s, go karts, and other transportation vehicles. Commercial uses include oil well pumps, tractors, tillers, lawnmowers, construction, and industrial equipment
Replaces OEM Part Numbers:Replaces 209151, 209151A, MANCO 2432
Compatible on most engines with horizontal shaft. Briggs, Robin, Tecumseh, Honda (and clones), Kohler, Clinton, Lifan
Specifications:
Driven clutch bore: 5/8″
Key Way: 3/16″
Outside Diameter: 7-1/2″
Belt: Symmetrical type
Engagement range: 1600 – 3300 RPM
