100% brand new items, never used or installed.
4-Bolt CT26 turbocharger + internal wastegate.
Made by OEM approved manufacturers with materials that meets or exceeds strict OEM requirements.
Manufactured from high quality cast aluminum & cast iron for superior strength and durability.
Included internal wastegate will be set around 0.7 BAR / ~10 PSI (can also be modified to use external wastegate).
SPECIFICATIONS (Estimated):
Exhaust Manifold Flange:
Standard 4-Bolt
Downpipe Exhaust Flange:
CT26 4-Bolt
Intake:
Inlet: 3.0″ / 76.2mm
Outlet: 2.25″ / 57.15mm
Compressor:
A/R: 0.60 A/R
Inducer: 1.66″ / 42.20mm
Exducer: 2.56″ / 64.95mm
Turbine:
A/R: 0.64 A/R
Inducer: 2.66″ / 67.55mm
Exducer: 2.04″ / 51.90mm
* Doesn’t include hardware such as gaskets, bolts, & nuts. Additional modifications and/or items are required to complete installation. *
No installation guides are included, we highly recommend seeking professional installation.
Compatible/Replacement For:
1990-1997 Toyota Land Cruiser (HDJ80)
1990-1993 Toyota Coaster (HDB20)
** Fits models with 1HD-T / 1HD-FT 4.2L turbocharged diesel engines only.
