Rear Left or Right Carrier Bushing Pivot Shaft Cap for Polaris Ranger XP 1000 20 (For: Polaris)
Rear Left or Right Carrier Bushing Pivot Shaft Cap for Polaris Ranger XP 1000 20 (For: Polaris)
Rear Left or Right Carrier Bushing Pivot Shaft Cap for Polaris Ranger XP 1000 20 (For: Polaris)
Premium Quality Replacement Part
Rear Wheel Bearing Left or Right Carrier Bushing w/ Pivot Shaft & CapFor Polaris Models:Ranger XP 1000 Edition 2020
Order Includes:
1 x Sealed Pivot Cap | 1543612Width : 10.1mm | 0.39″
Inner Diameter : 10.4mm | 0.41″
Outer Diameter : 26.4mm | 1.04″
1 x Pivot Shaft | 5139991Length : 119.5mm | 4.7″
Inner Diameter : 12mm | 0.47″
Outer Diameter : 19mm | 0.74″
1 x Bushing | 5452233Width : 15.5mm | 0.61″
Inner Diameter : 16.5mm | 0.64″
Outer Diameter : 26mm | 1.02″
Note : Installs On Location ( F ) In Second Picture
Rear Wheel Bearing Left Carrier Part Number : 5140866Rear Wheel Bearing Right Carrier Part Number : 5140867Rear Control Left A-Arm Part Number : 1022803-458Rear Control Right A-Arm Part Number : 1022802-458
**
