Set of CV Axles for Arctic Cat 400 & 500 FIS 4×4 03-04
Set of CV Axles for Arctic Cat 400 & 500 FIS 4×4 03-04
Set of CV Axles for Arctic Cat 400 & 500 FIS 4×4 03-04
This is a set of new Front or Rear CV axles for an Arctic Cat ATV.They fit the following 4×4 models:2003-2004 … 400 FIS MT/AT, TBX 4002003-2004 … 500 FIS MT/AT, TBX 500, & TRV 500Front & Rear, Left & Right*Not intended for use in lifted vehiclesProduct features:
Stronger than OEM chromoly hardened steel axle bars
Greased with a moly based grease to provide superior joint lubrication
Fitted with neoprene CV boots for added wear and puncture resistance
Inboard CV joint spline count: 21 (all)
Outboard CV joint spline count: 21 (all)
Compressed overall axle length: 548 mm (all)
Replaces Arctic Cat OE # 0402-907, 0502-544, 1502-442
