Premium Quality Replacement Part
Tail Light Assembly Bracket and Hardware for Yamaha Blaster 200 YFS200 2002-2006
High Quality Tail Light Assembly with Matching Bracket and Mounting Hardware for many Yamaha ATVs
Fits the Following YAMAHA Models
Banshee 350 YFZ350 2002-2006
Banshee 350 SE YFZ350SE 2005-2006
Banshee 350 LE Limited Edition YFZ350LE 2003 2004
Banshee 350 SP YFZ350SP 2006
Blaster 200 YFS200 2002-2006
Blaster 200 SE YFS200SE 2006
Breeze 125 YFA1 2002-2004
Warrior 350 YFM350X 2002-2004
Grizzly 125 YFM125 2004-2013
Grizzly 125 Hunter YFM125GH 2005-2008
Replaces Yamaha Part Numbers
Tail Light Bracket Mount | 3FA-84702-10-00
Grommet x2 | 90480-14229-00
Grommet x2 | 90480-14088-00
Collar x2 | 90480-14229-00
Collar x2 | 90387-06201-00
Washer x2 | 90201-06033-0
Washer x2 | 90210-06097-0
M6 Flange Bolt x2 | 95817-06025-00
M6 Nut x2 | 95380-066600-00
Spring Washer x2 | 92995-06100-00
Dimensions & Measurements
Short Mount Spacing | 70mm | 2.76″
Long Mount Spacing | 185mm | 7.28″
Mounting Bolts | M6x1.0x25mm
Order Includes
1x Tail Light Assembly
1x P21 5w 12v Bulb and Socket
1x Tail Light Bracket
1x M6 Mounting Hardware
