Turbo Charger 171702 S400SX4 S475 75mm T6 1.32 A/R Twin Scroll For DDC-MTU Truck
Turbo Charger 171702 S400SX4 S475 75mm T6 1.32 A/R Twin Scroll For DDC-MTU Truck
Turbo Charger 171702 S400SX4 S475 75mm T6 1.32 A/R Twin Scroll For DDC-MTU Truck
OE Number
171702, 23518588, 23518597,
23523197, 2585838C91, T915492, 23518567
Will fit Following Models
Turbo Model: S400S062
Engine Code: Series 60
Hosepower: 500-1050 HP
Turbine Housing A/R: 1.32
Turbine Housing Inlet: T6
Turbine
Turbine Inducer: 95.75mm
Turbine Exducer: 87.95mm
Turbine Wheel: 10 Blades
Turbine Exhaust Inlet: Twin Scroll T6 Flange
Turbine Exhaust Outlet: 5??for Marmon S400
Compressor
Compressor Inducer: 74.6mm
Compressor Exducer: 105.4mm
Compressor Wheel: 7+7 Blades
Compressor air inlet: 5.00″ ported anti-surge
Compressor Air Outlet: 4.21″ charge pipe outlet
Applications:
for DDC-MTU Truck with Series 60 Engine 2000-2008
for Navistar Truck with Series 60 Engine 2000-2008
for Int Harvester Truck with Series 60 Engine 2000-2008
